Allen Engineering TRTP75 – Triple Roller Tube Pavers

The lightest weight and least expensive machine in the TRTP product group, the 75 enables contractors to use a machine that handles small paving pours that would otherwise be too heavy for a truss screed. This unit is a nice addition to the Triple Tube Paver Group with some of the features and functions of the larger size machines.

Add to quote
Categories: , ,

Description

ENGINE – HONDA EFI
HORSEPOWER CLASS – 22 hp / 27.6 kW
FUEL TYPE – Gasoline
WIDTHS AVAILABLE (2 FT INCREMENTS) – 14 – 22 ft / 3.6 – 9.7 m
WEIGHT – 2,626 lbs / 1,191 kg
ROLLER TUBE DIAMETER – 6″ or 8″
TUBE WEIGHT PER FT – 19 / 21 lbs / 9 / 9.5 kg
HYDRAULIC OIL RESERVOIR – 9 gal / 34 L
HYDRAULIC SPRAY SYSTEM – OPTION
HYDRAULIC STEERING LEG – OPTION
