Description
Weights
- Operating weight: 298 lb
- Basic weight: 291 lb
Dimensions
-
- Lowest passing height: 26 in
- Min. Height w. steering in top position: 36.6 in
- Max height w. steering in top position: 49.2 in
Drive Characteristics
- Working speed max: 82 ft/min
- Max. gradeability (dep. on soil con.): 30%
Drive
- Engine Manufacture: Honda
- Type: GX 160
- Emission stage: Stage V / CARB P.3
- Cooling: Air
- Number of cylinders: 1
- Performance SAE J 1349: 4.8 hp
- Speed: 3,600 rpm
- Drive system: Mech.
- Fuel: Gasoline
- Fuel comsump. aver. during operation: 0.3 gal/h
Exciter System
- Frequency: 85 vpm
- Centrifugal force: 5,620 lb
- Amplitude: 0.061 in
Capacities
- Fuel: 0.8 gal
- Water: 3.2 gal
Standards
- Protective engine covering
- Comfortable control lever
- Low vibration steering rod
- Height adjustable steering rod
- Steering rod lockable in transport and working position
- Vibration and throttle regulation on the steering rod
- Highly wear-resistant, powder-coated base plate
- Fully protected V-belt
- Recoil starter
- Back-up drive protection
- Automatic shutdown at low oil level (BPR25/40)
- Automatic decompression (BPR25/40D)
- 3-2-1 Warranty
