Multiquip Whiteman WBH16F

Multiquip Whiteman WBH16F

  • Payload capacity 21 cubic foot (595 L)
  • Maximum load capacity 3200 Lbs. (1451 kg)
  • High density polyethylene tub will withstand the toughest use
  • 18 Horsepower Vanguard engine
  • Starting system recoil and electric start
  • Travel speed: 7.25 mph (11.6 km)
  • Large fuel capacity 4.8 gallon (18.1 L) for uninterrupted operation
  • Superflex foam filled tires provide a soft air-like ride while extending tire life

Multiquip Whiteman WBH16F is the perfect piece of equipment to have around any yard or jobsite. With its large payload capacity and easy maneuverability, this unit is great to move a multitude of materials or liquid material. Also, with its vertical lift bucket, it is great for transporting and pouring concrete, mulch, sand, dirt, gravel, rocks and much, much more. If you find yourself in need of such a piece of equipment this is your sign to reach out to us and lets make this happen.

WBH-16F

Unit Specifications
Drive System Infinitely variable, fully hydrostatic
Tub Material Polyethylene
Tub Capacity 16 cu. f
Travel Speed 7.25 mph 12 kph
Fuel Tank Capacity 5.5 gal
Approx. Running Time 8 hours
Lifting Assistance Forklift Pockets
Dimensions & Weights
Overall Length 103 in 2616.2 mm
Overall Width 44 in 1117.6 mm
Overall Height 51 in 1295.4 mm
Operating Weight 1135 lb 517.1 kg
Wheel Specifications
Tires Foam-Filled
Wheel Width 44 in 1117.6 mm
Front Wheel Width
Single Wheels
30.75 in 781 mm
Max. Load
Dual Wheels
2500 lb 1134 kg
Max. Load
Single Wheels
1000 lb 453.6 kg

WBH-16EF

Drive System Infinitely variable, fully hydrostatic
Tub Material Polyethylene
Tub Capacity 16 cu. f
Travel Speed 7.25 mph 12 kph
Fuel Tank Capacity 5.5 gal
Approx. Running Time 8 hours
Lifting Assistance Forklift Pockets
Dimensions & Weights
Overall Length 103 in 2616.2 mm
Overall Width 44 in 1117.6 mm
Overall Height 51 in 1295.4 mm
Operating Weight 1140 lb 517.1 kg
Wheel Specifications
Tires Foam-Filled
Wheel Width 44 in 1117.6 mm
Front Wheel Width
Single Wheels
30.75 in 781 mm
Max. Load
Dual Wheels
2500 lb 1134 kg
Max. Load
Single Wheels
1000 lb 453.6 kg



WBH-21EF

Unit Specifications
Drive System Infinitely variable, fully hydrostatic
Tub Material Polyethlene
Tub Capacity 21 cu. f
Travel Speed 7.25 mph 11.6 kph
Fuel Tank Capacity 4.8 gal
Approx. Running Time 8 hours
Lifting Assistance Forklift Pockets
Dimensions & Weights
Overall Length 103 in 261.6 mm
Overall Width 44 in 111.7 mm
Overall Height 51 in 129.5 mm
Operating Weight 1492 lb 676.7 kg
Wheel Specifications
Tires Superflex Foam-Filled
Wheel Width 43 in 1092 mm
Max. Load
Dual Wheels
3200 lb 1451 kg

WBH-21EFP

Unit Specifications
Drive System Infinitely variable, fully hydrostatic
Tub Material Polyethlene
Tub Capacity 21 cu. f
Travel Speed 7.25 mph 11.6 kph
Fuel Tank Capacity 7.5 gal
Approx. Running Time hours
Lifting Assistance Forklift Pockets
Wheel Specifications
Tires Superflex foam filled tires
Wheel Width 44 in 1117 mm
Max. Load
Dual Wheels
3200 lb 1451 kg

WBH-16EF

Drive System Infinitely variable, fully hydrostatic
Tub Material Polyethylene
Tub Capacity 16 cu. f
Travel Speed 7.25 mph 12 kph
Fuel Tank Capacity 5.5 gal
Approx. Running Time 8 hours
Lifting Assistance Forklift Pockets
Dimensions & Weights
Overall Length 103 in 2616.2 mm
Overall Width 44 in 1117.6 mm
Overall Height 51 in 1295.4 mm
Operating Weight 1140 lb 517.1 kg
Wheel Specifications
Tires Foam-Filled
Wheel Width 44 in 1117.6 mm
Front Wheel Width
Single Wheels
30.75 in 781 mm
Max. Load
Dual Wheels
2500 lb 1134 kg
Max. Load
Single Wheels
1000 lb 453.6 kg



WBH-21EF

Unit Specifications
Drive System Infinitely variable, fully hydrostatic
Tub Material Polyethlene
Tub Capacity 21 cu. f
Travel Speed 7.25 mph 11.6 kph
Fuel Tank Capacity 4.8 gal
Approx. Running Time 8 hours
Lifting Assistance Forklift Pockets
Dimensions & Weights
Overall Length 103 in 261.6 mm
Overall Width 44 in 111.7 mm
Overall Height 51 in 129.5 mm
Operating Weight 1492 lb 676.7 kg
Wheel Specifications
Tires Superflex Foam-Filled
Wheel Width 43 in 1092 mm
Max. Load
Dual Wheels
3200 lb 1451 kg

WBH-21EFP

Unit Specifications
Drive System Infinitely variable, fully hydrostatic
Tub Material Polyethlene
Tub Capacity 21 cu. f
Travel Speed 7.25 mph 11.6 kph
Fuel Tank Capacity 7.5 gal
Approx. Running Time hours
Lifting Assistance Forklift Pockets
Wheel Specifications
Tires Superflex foam filled tires
Wheel Width 44 in 1117 mm
Max. Load
Dual Wheels
3200 lb 1451 kg

WBH-21EF

Unit Specifications
Drive System Infinitely variable, fully hydrostatic
Tub Material Polyethlene
Tub Capacity 21 cu. f
Travel Speed 7.25 mph 11.6 kph
Fuel Tank Capacity 4.8 gal
Approx. Running Time 8 hours
Lifting Assistance Forklift Pockets
Dimensions & Weights
Overall Length 103 in 261.6 mm
Overall Width 44 in 111.7 mm
Overall Height 51 in 129.5 mm
Operating Weight 1492 lb 676.7 kg
Wheel Specifications
Tires Superflex Foam-Filled
Wheel Width 43 in 1092 mm
Max. Load
Dual Wheels
3200 lb 1451 kg

WBH-21EFP

Unit Specifications
Drive System Infinitely variable, fully hydrostatic
Tub Material Polyethlene
Tub Capacity 21 cu. f
Travel Speed 7.25 mph 11.6 kph
Fuel Tank Capacity 7.5 gal
Approx. Running Time hours
Lifting Assistance Forklift Pockets
Wheel Specifications
Tires Superflex foam filled tires
Wheel Width 44 in 1117 mm
Max. Load
Dual Wheels
3200 lb 1451 kg

WBH-21EFP

Unit Specifications
Drive System Infinitely variable, fully hydrostatic
Tub Material Polyethlene
Tub Capacity 21 cu. f
Travel Speed 7.25 mph 11.6 kph
Fuel Tank Capacity 7.5 gal
Approx. Running Time hours
Lifting Assistance Forklift Pockets
Wheel Specifications
Tires Superflex foam filled tires
Wheel Width 44 in 1117 mm
Max. Load
Dual Wheels
3200 lb 1451 kg
Dimensions & Weights
Overall Length 103 in 261.6 mm
Overall Width 44 in 1117 mm
Operating Weight 1570 lb 712.1 kg
