TB11PG
Its robust 4-wheel drive provides excellent climbing ability and superior traction in mud or sand. A patented articulated design delivers excellent maneuverability and a tight turning radius. The standard 10.6 ft³ capacity polyethylene tub carries material or debris and passes through 36-inch openings.
Choose between an innovative, zero emission, battery drive (TB11PE) or 5.5 HP Honda gas engine with hydraulic drive. (TB11PG)
Articulating-Joint
Excellent maneuverability with 40° articulation angle and 58-inch turning radius
Unit Specifications
| Power Supply |
Honda GX200 5.5 HP Gasoline |
| Starting System |
Manual Recoil |
| Drive & Controls |
4×4 – Hydrostatic system |
| Travel Speed – Forward |
0 to 3.5 MPH |
0 to 5.6 KPH |
| Travel Speed – Reverse |
0. 1.5 MPH |
0 to 2.4 KPH |
| Bucket Material |
Polyethylene |
| Gradability |
25 % |
| Oscillation |
6 ° |
| Articulation |
40 ° |
| Noise Levels |
69 dBA |
| Notes:58 in. turning radius |
Wheel Specifications
| Tires |
16×6.50-8 Pneumatic |
| Wheel Width |
34.5 in |
876.3 mm |
| Wheel Width (Reversed) |
29.5 in |
749.3 mm |
Max. Load
Single Wheels |
990 lb |
449 kg |
Dimensions & Weights
| Overall Length |
68.5 in |
1740 mm |
| Overall Width |
34.5 in |
876.3 mm |
| Overall Height |
38 in |
965.2 mm |
| Operating Weight |
561 lb |
254.5 kg |
TB11G
Its robust 4-wheel drive provides excellent climbing ability and superior traction in mud or sand. A patented articulated design delivers excellent maneuverability and a tight turning radius. The standard 10.6 ft³ capacity steel tub carries material or debris and passes through 36-inch openings.
Choose between an innovative, zero emission, battery drive (TB11E) or 5.5 HP Honda gas engine with hydraulic drive. (TB11G)
Articulating-Joint
Excellent maneuverability with 40° articulation angle and 58-inch turning radius
Unit Specifications
| Power Supply |
Honda GX200 5.5 HP Gasoline |
| Starting System |
Manual Recoil |
| Drive & Controls |
4×4 – Hydrostatic system |
| Travel Speed – Forward |
0 to 4 MPH |
0 to 6 KPH |
| Travel Speed – Reverse |
0 to 1.5 MPH |
0 2.4 KPH |
| Bucket Material |
Steel |
| Gradability |
25 % |
| Oscillation |
6 ° |
| Articulation |
40 ° |
| Noise Levels |
69 dBA |
Wheel Specifications
| Tires |
16×6.50-8 Pneumatic |
| Wheel Width |
34.5 in |
876.3 mm |
| Wheel Width (Reversed) |
29.5 in |
749.3 mm |
Dimensions & Weights
| Overall Length |
68.5 in |
1740 mm |
| Overall Width |
34.5 in |
876.3 mm |
| Overall Height |
38 in |
965.2 mm |
| Operating Weight |
396 lb |
179.6 kg |
TB12PE
Its robust 4-wheel drive provides excellent climbing ability and superior traction in mud or sand. A patented articulated design delivers excellent maneuverability and a tight turning radius. The standard 10.6 ft³ capacity steel tub carries material or debris and passes through 36-inch openings.
Choose between an innovative, zero emission, battery drive (TB11E) or 5.5 HP Honda gas engine with hydraulic drive. (TB11G)
Articulating-Joint
Excellent maneuverability with 40° articulation angle and 58-inch turning radiusBattery Powered Electric Drive
Battery Powered Electric Drive
- Zero emission, high torque electric drive provides solid 8 hour run time under full load
- Long lasting charge lasts 2 to 3 days working under typical conditions
- Integral battery charger uses standard 120 Volt power and features over charge protection
Unit Specifications
| Power Supply |
Two Brushless motors 750W / 24V |
| Starting System |
Electric |
| Battery Type |
2×12 V AGM Deep Cell Batteries |
| Drive & Controls |
4×4 – 24V Motor Gearbox |
| Travel Speed – Forward |
0 to 3.5 MPH |
0 to 5.6 KPH |
| Travel Speed – Reverse |
0. 1.5 MPH |
0 to 2.4 KPH |
| Bucket Material |
Polyethylene |
| Gradability |
25 % |
| Oscillation |
9 ° |
| Articulation |
40 ° |
| Noise Levels |
76 dBA |
| Notes:56 in. turning radius |
Wheel Specifications
| Tires |
16 x 6.50 x 8 Pneumatic |
| Wheel Width |
28.6 in |
726 mm |
Max. Load
Single Wheels |
1100 lb |
499 kg |
Dimensions & Weights
| Overall Length |
70.3 in |
1786 mm |
| Overall Width |
33.4 in |
848 mm |
| Overall Height |
41.9 in |
1064 mm |
| Operating Weight |
529 lb |
240 kg |
TB12SE
Its robust 4-wheel drive provides excellent climbing ability and superior traction in mud or sand. A patented articulated design delivers excellent maneuverability and a tight turning radius. The standard 10.6 ft³ capacity steel tub carries material or debris and passes through 36-inch openings.
Choose between an innovative, zero emission, steel tub, battery drive (TB12SE) or 5.5 HP Honda gas engine with hydraulic drive and steel tub. (TB11G)
Articulating-Joint
Excellent maneuverability with 40° articulation angle and 58-inch turning radiusBattery Powered Electric Drive
Battery Powered Electric Drive
- Zero emission, high torque electric drive provides solid 8 hour run time under full load
- Long lasting charge lasts 2 to 3 days working under typical conditions
- Integral battery charger uses standard 120 Volt power and features over charge protection
